Optical fiber slurry TOB SO-120D fiber grinding fluid, is with our specially developed for fiber optic patch cord with precision polishing a polishing liquid. The grinding solution concentration up to 40%, far higher than other similar products on the market (20%) rubber uniform density, particle size distribution, good effects and polishing polishing rate; as a final polishing for fiber jumpers, their cost is much lower than polishing pad polishing.
Characteristics
|
features |
Model and standard |
|
SO-120D |
|
|
Particle size（nm） |
100-120 |
|
SiO2 Content (by weight) |
40±1%(We recommend diluted with water before use) |
|
Na2O Content (by weight) |
≤0.4% |
|
dispersion medium |
water |
|
Color |
oyster white |
|
decentralized state |
monodispersepolymer |
|
PH |
10-11 |
|
particle morphology |
Ball |
|
Warranty（Month） |
≥12（0℃以上） |
Product features
- High concentration, colloidal particles into spherical, dense structure,good quality of polishing, and polishing efficiency can be obtained.
- Particle size can be controlled, centralized distribution (± 10nm).
光纤研磨液 TOB SO-120D光纤研磨液，是以我司为光纤跳线精密抛光专门研制的一种研磨抛光液。该研磨液浓度高达40％，远高于市场上其它同类产品（20%）；胶粒致密均匀、粒度分布集中，具有良好的抛光速率和抛光效果；用作光纤跳线的最后抛光，其成本大大低于抛光片抛光。
基本特性
|
特性 |
型号及标准 |
|
SO-120D |
|
|
粒径（nm） |
100-120 |
|
SiO2含量（重量） |
40±1%（建议使用前加水稀释） |
|
Na2O含量（重量） |
≤0.4% |
|
分散介质 |
水 |
|
外观 |
乳白色 |
|
分散状态 |
单分散 |
|
PH值 |
10-11 |
|
胶粒形态 |
球型 |
|
保质期（月） |
≥12（0℃以上） |
产品特点
- 浓度高、胶粒成球形，结构致密，可获得良好的抛光质量和抛光效率。
- 粒径可控，分布集中（±10nm）。
包装及储存
1．采用聚乙烯塑料桶包装，主要包装规格有500ml、5kg。
2．贮存时应避免曝晒，贮存温度为0-40℃。低于0℃则产生冻胶失效。
3．避免敞口长期与空气接触。
